Aluminum Oxide (AIOx) Film
Aluminum oxide (AIOx) film is transparent and high barrier material with almost the same barrier performance as VMPET. It is widely used in food and non-food industries.
Overview:
The product with high barrier, high transparency (light transmittance ＞89%), could be printed, laminated, microwave heating, retort and boiling and is very environmentally friendly.
Application:
High-barrier food packaging, special electronic products, optical products, medical drugs, etc. that require microwave heating or product see-through display.
Specification:
Thickness 10-40μm, width 250-2000mm, length 3" (76mm) or 6" (152mm) inner diameter of the winding core according to customer requirements.
General Properties:
Item | PET000NO | PET001PR | PET002RO | |
Tensile Strength （MPa） | MD | ≥170 | ≥170 | ≥170 |
TD | ≥170 | ≥170 | ≥170 | |
Elongation （%） | MD | ≥80 | ≥80 | ≥80 |
TD | ≥80 | ≥80 | ≥80 | |
Heat Shrinkage | ≤1.5 | ≤1.5 | ≤1.5 | |
Coefficient of Friction | ≤2.0 | ≤2.0 | ≤2.0 | |
Wetting Tension | ≥42 | ≥42 | ≥42 | |
O2TR gm/[m²-day] | ≤3.5 | ≤1.5 | ≤1.0 | |
WVTR cc/[m²-day] | ≤3.5 | ≤1.5 | ≤1.0 | |
Key property | No Bottom Coating | Bottom Coating | Bottom Coating + Surface Coating | |
The data herein is measured on products which are reliable yet not guarantee value.
