BOPE with PVA Coating

PVA-coated BOPE film is one of the current innovations in flexible packaging. It is a high-performance material that represents the future development direction of flexible packaging, perfectly integrating the innovation of basic materials with environmentally friendly high-barrier technology.


It simultaneously overcomes the two core goals of high performance (high oxygen barrier, high strength and toughness) and sustainability (100% PE recyclable, thinning). It represents the most advanced path for the industry's transition to a circular economy.


It is not only an upgrade of traditional composite packaging, but also a definition of the future packaging form.

Contact Us

TDS of BOPE Film with PVA Coating

Product Name

25mic ABOPE

Testing Item

Unit

Standard

Testing Data

Testing Method

Thickness

μm

25±1.5

26

GB6672-2001

Tensile Strength

MD

Mpa

≧50

95


TD

Mpa

≧50

106


Elongation at break

MD

%

≦200

126

GB/T1040.3-2006

TD

%

≦200

96


C.O.F

μs

/

≦0.5

0.22

GB10006-1998

μk

/

≦0.5

0.21

Wetting Tension

mN/cm

≧38

40

GB/T 14216-2008

O2TR

cm3/m2.d.0.1Mpa

≦10

1.5

GB/T 19789-2021

WVTR

g/m2.d

≦10

6.8

GB/T 26253-2010


Main Performance Features of BOPE Film with PVA Coating

Outstanding oxygen barrier property

The PVA coating provides top-notch oxygen barrier performance in a dry environment, effectively preventing the oxidation and deterioration of contents, significantly extending the shelf life of products such as nuts, chips, pet food, and milk powder.

Unparalleled sustainability and recyclability
  • This is its most core advantage. The entire structure is made of full PE material. The PVA coating is extremely thin and is regarded as a compatible impurity during recycling, ensuring that the entire packaging can enter the PE recycling stream without any impact.

  • It successfully solves the industry problem of traditional high-barrier packaging (using aluminum foil, EVOH, PA, etc.) which is difficult to recycle due to multi-material composites. It is an ideal solution for achieving "single-material recyclable packaging".

Excellent structural strength and toughness

The BOPE base film provides superior puncture resistance and impact resistance compared to BOPP and ordinary PE, significantly reducing the bag breakage rate during transportation, especially suitable for heavy or contents with sharp edges packaging.

High transparency and lightweight

The film has high transparency, allowing for excellent display of the product. At the same time, BOPE itself can be thinned for use, combined with the ultra-thin PVA coating, achieving plastic reduction while maintaining higher performance.
