MDOPE with PVA Coating

The PVA-coated MDO-PE film is one of the leading materials in the current soft packaging industry, integrating high performance and environmental friendliness. Through the perfect combination of "MDO-PE base film" and "PVA coating", it ingeniously addresses the two seemingly conflicting core requirements of high barrier and recyclability.


It is not only a powerful alternative to traditional aluminum foil and EVOH composite bags, but also a key technological path that drives the packaging industry towards a single-materialization, lightweighting and sustainable development, representing an important future direction for packaging.

Contact Us

TDS of MDOPE Film with PVA Coating

Product Name

25mic AMDOPE

Testing Item

Unit

Testing Data

Testing Method

Thickness

μm

25

GB6672-2001

Density

g/m³

0.955

GBT/1033.3

Tensile Strength

MD

Mpa

136

GB/T1040.3-2006

TD

Mpa

24

Elongation at break

MD

%

90

TD

%

220

C.O.F

μs

/

0.3

GB10006-1998

μk

/

0.4

Wetting Tension

mN/cm

40

GB/T 14216-2008

O2TR

cm3/m2.d.0.1Mpa

1.5

GB/T 19789-2005

WVTR

g/m2.d

8

GB/T 26253-2010


Main Performance Characteristics of MDOPE Film with PVA Coating

Excellent oxygen barrier performance

Under low humidity conditions, the oxygen barrier performance of the PVA coating can surpass that of EVOH, effectively extending the shelf life of oxygen-sensitive foods (such as nuts, snacks, meats, and oils).

Perfect sustainability and recyclability
  • This is one of its core advantages. The entire structure is made of all-PE material (the PVA coating is extremely thin and is regarded as a compatible impurity during the recycling process, not affecting the PE recycling process), making it a single-material recyclable packaging.

  • It solves the problem of difficult recycling of traditional aluminum foil, PVDC or EVOH composite bags, perfectly aligning with global environmental policies and the sustainable development goals of brands.

High transparency and aesthetic appeal

The film has extremely high transparency, fully showcasing the contents. The MDO-PE base film provides good gloss and printability, giving the packaging a high-end appearance.

Lightweight and thinning

MDO-PE technology allows the use of thinner PE materials to achieve the required strength, combined with an extremely thin PVA coating, achieving material reduction under higher performance.
