Inflatable CPP

Inflatable CPP Film (inflatable polypropylene film) is a type of blown film specifically designed for manufacturing inflatable cushioning packaging materials. It represents a revolutionary innovation in modern logistics packaging technology.


It ingeniously utilizes air, the lightest and cheapest resource, as the buffering medium and encapsulates it with high-performance CPP film, creating a highly robust, lightweight, environmentally friendly, and highly efficient protective solution.


It not only redefines the standards for product transportation protection but also, with its remarkable energy-saving and emission-reduction advantages, becomes one of the core materials driving the development of green supply chains and sustainable packaging.
Contact Us

TDS of Inflatable CPP Film

Product Name

Inflatable CPP  film

Testing Item

Unit

Typical  Value

Testing Method

Basic CPP

High Gloss & Transparent CPP

Low Temperature CPP

Negative Pressure Resistance CPP

Thickness

μm

35μm

35μm

35μm

35μm

GB/T 6672

Tensile Strength

MD

Mpa

≥30

≥30

≥30

≥30

GB/T 1040.3

TD

Mpa

≥20

≥20

≥20

≥20

GB/T 1040.3

Elongation at break

MD

%

≥400

≥400

≥400

≥450

GB/T 1040.3

TD

%

≥500

≥500

≥500

≥550

GB/T 1040.3

C.O.F.   (untreated side)

-

0.3-0.7

0.3-0.7

0.4-0.8

0.3-0.7

GB10006

Heat Sealing Strength

N/15mm

≥8

≥8

≥8

≥8

QB/T 2358

Haze

%

≤3

≤2

≤3

≤3

GB/T 2410

Wetting Tension

Treated

mN/cm

≥40

≥40

≥40

≥40

GB/T 14216


Main Performance Features of Inflatable CPP Film

Excellent buffering and protective performance

The air cushion formed after inflation can provide excellent shock and vibration resistance, protecting products from damage during transportation, especially for fragile items such as electronic products, cosmetics, and alcohol.

Significant savings in storage and transportation space

Before inflation, the film rolls or un-inflated bags take up very little space, only 1/50 or even less of the inflated volume. This greatly saves storage space and transportation costs.

Environmental friendliness and sustainability
  • Single material: mainly composed of PP, it is a single-material recyclable packaging.

  • Reduction: compared with heavy foam boxes, it greatly reduces the use of raw materials.

  • It meets the requirements of modern green logistics and environmentally friendly packaging.

Lightweight

The film itself is very light, and the internal filling is air, making the entire packaging system very light and effectively reducing the weight and cost of logistics.

Easy to use

The number of air columns can be flexibly filled according to the size and quantity of the products, achieving "tailor-made" packaging protection, with simple and efficient operation.
