MCP Substrate
Vacuum aluminized substrates, firstly, require smooth, flat surface, and balanced thickness, as well as proper stiffness and friction coefficient. Second, it should have good thermal performance and be able to withstand the heat radiation and condensation heat of evaporation source. The common substrates for vacuum aluminum coating are PET, PP, PA, PE, PVC etc.
Overview:
Excellent smoothness, high gloss, good laminating performance and heat-sealing performance.
High adhesion of coating, excellent barrier property after aluminizing, high gloss, and very excellent dimensional stability after vaporizing.
Application:
After vacuum aluminizing, it can be dry and solvent-free laminated with BOPP, BOPET and other substrates for tea, snack food, labeling, pharmaceuticals, etc.
Specification:
Thickness 20-40μm, width 250-2000mm, length 3" (76mm) or 6" (152mm) inner diameter of paper core according to customer requirements.
General Properties:
Item | Normal MCP
| Low Temperature MCP | High Barrier MCP | High Adhesion MCP(A)
| High Adhesion MCP(B)
| High Gloss MCP | High Stiffness MCP | Toughened MCP | |
Tensile Strength （MPa） | MD | ≥35 | ≥35 | ≥35 | ≥35 | ≥35 | ≥35 | ≥40 | ≥40 |
TD | ≥25 | ≥25 | ≥25 | ≥25 | ≥25 | ≥25 | ≥30 | ≥30 | |
Elongation （%） | MD | ≥400 | ≥400 | ≥400 | ≥400 | ≥400 | ≥400 | ≥400 | ≥550 |
TD | ≥500 | ≥500 | ≥500 | ≥500 | ≥500 | ≥500 | ≥500 | ≥650 | |
Heat Seal Strength(N/15mm) | ≥8 | ≥7 | ≥10 | ≥8 | ≥8 | ≥8 | ≥8 | ≥12 | |
Coefficient of Friction | ≤0.7 | ≤0.7 | ≤0.7 | ≥0.7 | ≤0.7 | ≤0.7 | ≤0.7 | ≤0.7 | |
Wetting Tension | ≥38 | ≥38 | ≥38 | ≥38 | ≥38 | ≥38 | ≥38 | ≥38 | |
Haze | ≤3.5 | ≤3.5 | ≤4 | ≤5 | ≤5 | ≤3 | ≤4 | ≤3 | |
Main Property | / | 85-110℃ | O2TR-≤2.5 WVTR-≤25 | EAA≥1.5 | EAA≥2.5 | 60°-≥90 | Label | Negative Pressure Resistance | |
For further information please feel free to contact us. We will get back to you in 24 hours.The data herein is measured on products which are reliable yet not guarantee value.
